Dial Pointer String Driven 100200

- Description
- Specifications
This is a centered-bracket slide-rule dial pointer. It features a 1" x 1/4" mounting base with a 5/8" center bracket assembly aligned between the outer left and right bracket edges. Designed to attach to a tuning dial cord or guide track, it extends a 2-inch indicator needle across slide-rule glass dial scales. This style was commonly used in tabletop radios and consoles manufactured by companies like Philco, Zenith, RCA Victor, General Electric, and Crosley.
Product Type: Dial Pointer / Scale Indicator
Mounting Style: Centered Bracket Mount
Mount Base Dimensions: 1 inch x 1/4 inch (1.0 in x 0.25 in / 25.4 mm x 6.35 mm)
Center Bracket Width: 5/8 inch (0.625 in / 15.875 mm) centered
Overall Pointer Length: 2 inches (50.8 mm)
Application: Vintage radio tuning dial scale assemblies
